4ARXS HSD 150W/70

产品特点

Proven, reliable technology for entertainment and architectural fixtures
Designed with an outer quartz jacket providing compact and rugged construction
High luminous efficacy of up to 90 lumens/watt
4ARXS ("For Architainment eXtreme Seal") are designed to withstand temperatures up to 450°C at the pinch seal and provide longer lamp life of up to 3,000 hrs (when operated on an ECG)

应用领域

建筑照明及灯光秀
演唱会照明
舞会及俱乐部

安全建议
由于4ArXS HSD灯在工作时亮度高、紫外线辐射高、内压高，所有它只能在专为此目的设计的密闭外壳内工作。必须使用合适滤光片来确保紫外线辐射降至接受水平。如果灯破裂，会释放水银。必须采取特定的安全措施。备有安全性和处理相关信息可供索取，也可以在照明灯宣传单或操作说明书中查找相应信息。

数据参数表

技术数据

General Product Information

NAED5

54311

Description

4ARXS HSD 150W/70 10/CS 1/SKU

Family Brand Name

4ArXS HSD

Lamp Type

SINGLE END

产品简述集合

4ARXS HSD 150W/

电参数

标称功率

150 W

标称电压

97.0 V

标称电流

1.6 A

电流类型

光度数据

光通量

12000 lm

色温

7000 K

显色指数 Ra

Physical Attributes & Dimensions

灯头 (标准名称)

G12

Diameter (in)

0.787 in

直径

20.0 mm

长度

105.0 mm

产品重量

31.20 g

寿命

Average Rated Life

3000 hr

Environmental & Regulatory Information

Information according Art. 33 of EU Regulation (EC) 1907/2006 (REACh)

Primary Article Identifier

4008321625847

Declaration No. in SCIP database

No declarable substances contained

Candidate List Substance 1
