Lightbar FX500-CB SM
LED auxiliary lights enhance driving pleasure
Improved far field illumination on dark rural and dirt roads – it’s no problem for the LEDriving Lightbar FX500-CB. Its 20 intense, high-performance LEDs give the LED high beam a light distance up to 440 meters and ensure improved road safety for drivers.
Even at dusk or in compromised lighting conditions, the LED bars for automobiles provide daylight conditions at a strong 6000 Kelvin without needlessly blinding oncoming traffic. The intelligent reflector design diverts the light from the LEDs so that oncoming traffic is only indirectly exposed to the light. The light is evenly distributed at a five degree angle.
Robust, durable and versatile
Whether used as a LED working light or as an auxiliary high beam for the car – the powerful performance and long life of the LEDriving Lightbar FX500-CB make it a compelling choice. Equipped for a wide range of uses, it defies environmental factors and is particularly robust thanks to the quality craftsmanship of its materials and hard-wearing polycarbonate lens.
The integrated driver and thermal management system regulates the temperature of the LED automotive headlight and prevents damage caused by overheating. Full polarity protection ensures the LEDs are automatically shut off in the event of excess voltage.
Brightness for a wide range of uses
The LEDriving Lightbar FX500-CB is pure pleasure both on and off-road. The ECE-compliant LED auxiliary light ensures better visibility and thus improved safety on roads. In addition, it adds a smart touch that enhances the off-road style of the vehicle.
The LED headlight can be mounted on 12V vehicles as well as agricultural machines, utility vehicles, recreational, off-road and 4x4 vehicles. The power package with an intense 5500 lumen brightness scores with the highest optical efficiency and homogeneous light distribution with reduced glare.
Even at dusk or in compromised lighting conditions, the LED bars for automobiles provide daylight conditions at a strong 6000 Kelvin without needlessly blinding oncoming traffic. The intelligent reflector design diverts the light from the LEDs so that oncoming traffic is only indirectly exposed to the light. The light is evenly distributed at a five degree angle.
Robust, durable and versatile
Whether used as a LED working light or as an auxiliary high beam for the car – the powerful performance and long life of the LEDriving Lightbar FX500-CB make it a compelling choice. Equipped for a wide range of uses, it defies environmental factors and is particularly robust thanks to the quality craftsmanship of its materials and hard-wearing polycarbonate lens.
The integrated driver and thermal management system regulates the temperature of the LED automotive headlight and prevents damage caused by overheating. Full polarity protection ensures the LEDs are automatically shut off in the event of excess voltage.
Brightness for a wide range of uses
The LEDriving Lightbar FX500-CB is pure pleasure both on and off-road. The ECE-compliant LED auxiliary light ensures better visibility and thus improved safety on roads. In addition, it adds a smart touch that enhances the off-road style of the vehicle.
The LED headlight can be mounted on 12V vehicles as well as agricultural machines, utility vehicles, recreational, off-road and 4x4 vehicles. The power package with an intense 5500 lumen brightness scores with the highest optical efficiency and homogeneous light distribution with reduced glare.
技术数据
Product information
Application (Category and Product specific)
Additional high beam application
General Product Information
Order reference
LEDDL104-CB SM
电参数
标称电压
12/24 V
测试电压
13.5 V
光度数据
光通量
5500 lm
色温
6000 K
Physical Attributes & Dimensions
产品重量
2100.00 g
寿命
使用寿命 Tc
5000 hr
Guarantee
5 年
更多的产品数据
光源连接头
DT Connector
功能
Technology
LED
认证与标准
防护类型
IP67
认证标志 – 认证
E4 认证
标准
ECE R10, R112
物流数据
商品编码 [PICOS]
85122000900
Environmental & Regulatory Information
Information according Art. 33 of EU Regulation (EC) 1907/2006 (REACh)
Primary Article Identifier
4052899614079
Candidate List Substance 1
Lead
CAS No. of substance 1
7439-92-1
Safe Use Instruction
The identification of the Candidate List substance is sufficient to allow safe use of the article.
Declaration No. in SCIP database
6da87b7d-5e14-42a4-b600-16a278fbfb38
包装信息
EAN |
单位 |
件 |
尺寸 |
重量 |
音量 |
---|---|---|---|---|---|
4052899614079 |
FS
| 1 | 638mm x 137mm x 90mm | 2399.00g | 7.87dm³ |
4052899614086 |
VS
| 4 | 655mm x 295mm x 208mm | 10238.00g | 40.19dm³ |
